(100) MS35191-278 Machine Screw 3/8" x 1 1/2" 55,000PSI NSN:5305-00-984-7352
Please fill out the form below for a price quote and availability on this item.
Machine Screw
NSN: 5305-00-984-7352 | Model: MS35191-61
Replacements:
- 5305-00-984-7352 replaces 5305-00-059-7056
- 5305-00-984-7352 replaces 5305-00-582-5902
Schedule B & Trade:
- Schedule B: 7318152000 (NAICS 332722)
Bolts and bolts and their nuts or washers exported in the same shipment
- SITC: 69421
Screws, bolts, nuts, screw hooks, rivets, washers and similar articles, threaded, of iron or steel
- End Use: 12110
Iron and steel products, other
NSN Properties and Flags
NATO Stock Number
5305-00-984-7352
DEMIL
Yes - ITAR Controlled
Thread Class
2a
Thread Direction
Right-hand
Thread Length
Between 1.438 inches and 1.500 inches
Fastener Length
1.500 inches
Head Style
Flat countersunk
Head Diameter
Between 0.340 inches and 0.385 inches
Internal Drive Style
Cross recess type 1
Thread Diameter
0.190 inches
Thready Qty Per Inch (tpi)
32
Min. Tensile Strength (psi)
55000 pounds per square inch
Countersink Angle
Between 80.0 degrees and 82.0 degrees
Screw Material
Steel comp 1010 or steel comp 1011 or steel comp 1013
Screw Material Specification
66 federal standard all material responses
Screw Surface Treatment
Cadmium and chromate
Screw Surface Treatment Specification
Qq-p-416 type 2 cl 3 federal specification single treatment response
Thread Series Designator
Unf
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
