BUSSMAN
NSN 5920-00-052-7172
Bussman NOS-45 50amp,600V Cartridge Fuse NSN:5920-00-052-7172
Regular price
$8.99
Cartridge Fuse
SKU: 5920000527172 | Model: P8-C5-E45NSN 5920-00-052-7172
Description:
Tube type body style, brass terminal material, nickel terminal surface treated, 5.500" length, 1.062" diameter
Specifications from the Manufacturer
Body Style:
Tube type
Terminal Material:
Brass
Terminal Surface Treatment:
Nickel
Overall Length:
5.500 inches nominal
Overall Diameter:
1.062 inches nominal
Case Material:
Fiber
Continuous Current Rating In Amps:
45.000
Maximum Voltage Rating In Volts:
600.0 ac and 600.0 dc
Circuit Over-current Interruption Type:
Normal instantaneous
Interruption Indicator Method:
Opaque body
Features Provided:
Nonrenewable fusible element
Short-circuit/interrupt Current Rating In Amps:
200000.0
