50/60Hz Rohs Transformer P/N:HS14F5BS
Regular price
$495.00
Electrical Group, Transformer, Input Voltage 190/220 x 380/440, Output Voltage 110/220, 50/60 Hertz Length 10" Width 9" Height 17" Nominal, Catalog No HS14F5BS
The HS14F5BS is a non-ventilated Automation Transformer rated for hazardous locations as well as harsh industrial environments. Encapsulation and rugged UL Listed/NEMA Type 3R enclosures protect the transformer from dust, moisture and provide extra shock and vibration resistance. The transformers fully comply with the latest addition of the National electrical code for class I, division 2, group A, B, C and D locations when installed in compliance with NEC 501.100 (B). It is encapsulated with electrical grade silica and epoxy for industrial applications.
- Electrostatically shielded for quality power on sizes 1kVA and larger
- UL Class 200°C insulation system, 115°C temperature rise under full load
- Conduit knockouts for side entry into wiring compartment
- Copper lead-wire terminations
| Configuration | : | NEMA/Encapsulated |
| Current, Primary | : | 22.7/11.4 A |
| Current, Secondary | : | 45.5/22.7 A |
| Frequency | : | 50/60 Hz |
| Phase | : | 1 |
| Power, Rating | : | 5 kVA |
| Type | : | Auto |
| Voltage, Primary | : | 190/200/208/220/380/400/415/440/200/208/230/400/415/460/208/240/415/480 VAC |
| Voltage, Secondary | : | 110/220/115/230/120/240 V |
